Our products for your air conditioning
If you cannot find a suitable product for your requirements here, please contact us.
BRS
2-terminal resistor made of composite material. Ideal for use on DCB. Shackle shape, high cycle stability.
| Product area: | Resistor |
|---|---|
| Size: | 3812 |
| Power (Watt): | 1 - 2 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.002 - 0.025 |
CMK
2-terminal resistor for medium power requirements. Low TC <50ppm/K for the entire value range.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 0.5 - 4 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.005 - 0.1 |
CMP
2-terminal resistor for medium power requirements. Low TC <50ppm/K for the entire value range.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 1 - 2 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.01 - 0.5 |
CMS
2-terminal resistor for medium power requirements. Low TC <50ppm/K for the entire value range.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 2 - 2.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.01 - 0.5 |
FMK
2-terminal resistor. Low resistance values <=6 milliohms. Good TC. Solid construction as metal plate. High pulse load.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 1 - 3.5 |
| Tol (%): | 1.00 - 10.0 |
| Res (Ohm): | 0.002 - 0.006 |
FMP
2-terminal resistor. Low resistance values <=6 milliohms. Good TC. Solid construction as metal plate. High pulse load.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 1 - 3.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.002 - 0.006 |
SMK
2-terminal resistor with large solder pads. Very powerful. Largest selection of resistor values up to 0.5 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 1 - 1.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.008 - 0.5 |
SMP
2-terminal resistor with large solder pads, very powerful. Largest selection of resistor values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 2 - 3 |
| Tol (%): | 0.500 - 1.00 |
| Res (Ohm): | 0.005 - 1 |
SMS
2-terminal resistor with large solder pads. Very powerful. Largest selection of resistance values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 3 - 5 |
| Tol (%): | 0.500 - 5.00 |
| Res (Ohm): | 0.005 - 1 |
SMT
2-terminal resistor with large solder pads. Very powerful. Largest selection of resistor values up to 4.7 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2817 |
| Power (Watt): | 5 - 7 |
| Tol (%): | 0.500 - 5.00 |
| Res (Ohm): | 0.004 - 4.7 |
VMK
2-terminal resistor. Standard solder pad geometry. Very low TC <20ppm/K for the entire value range. High continuous load, wide range of resistance values up to 470 mOhm.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 1 - 1.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.01 - 0.47 |
VMP
2-terminal resistor. Standard solder pad geometry. Very low TC <20ppm/K for the entire value range. High continuous load. Wide range of resistance values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 2 - 3 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.005 - 1 |
VMS
2-terminal resistor. Standard solder pad geometry. Very low TC <20ppm/K for the entire value range. High continuous load. Wide range of resistance values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 3 - 4 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.005 - 1 |
