Our products for your power supply
If you cannot find a suitable product for your requirements here, please contact us.
A-H
4-terminal resistor with low TC. Low resistance values for high accuracy. 10 W power – mounted on heat sink.
| Product area: | Resistor |
|---|---|
| Size: | 4618 |
| Power (Watt): | 3 - 10 |
| Tol (%): | 0.100 - 1.00 |
| Res (Ohm): | 0.001 - 100 |
AZ-H
4-terminal resistor with optimized TC. 10 W power – mounted on heat sink.
| Product area: | Resistor |
|---|---|
| Size: | 4618 |
| Power (Watt): | 3 - 10 |
| Tol (%): | 0.100 - 1.00 |
| Res (Ohm): | 0.002 - 5 |
BVE
2-terminal resistor made of composite material. Very low resistance values. Large connectors for high currents.
| Product area: | Resistor |
|---|---|
| Size: | 5930 |
| Power (Watt): | 4 - 15 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.0001 - 0.003 |
BVH
2-terminal resistor made of composite material. Large connectors for high currents.
| Product area: | Resistor |
|---|---|
| Size: | 3820 |
| Power (Watt): | 5 |
| Tol (%): | 3.00 - 5.00 |
| Res (Ohm): | 0.0005 |
BVS
2-terminal resistor made of composite material. Very low resistance values. Large connectors for high currents.
| Product area: | Resistor |
|---|---|
| Size: | 3920 |
| Power (Watt): | 2.5 - 12 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.0001 - 0.005 |
BVT
2-terminal resistor made of composite material. Very low resistance values. Large connectors for high currents.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 1.5 - 10 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.0002 - 0.0068 |
CMK
2-terminal resistor for medium power requirements. Low TC <50ppm/K for the entire value range.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 0.5 - 4 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.005 - 0.1 |
CMP
2-terminal resistor for medium power requirements. Low TC <50ppm/K for the entire value range.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 1 - 2 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.01 - 0.5 |
CMS
2-terminal resistor for medium power requirements. Low TC <50ppm/K for the entire value range.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 2 - 2.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.01 - 0.5 |
IEM-DCR-1000
The IEM-DCR-1000 complies with the German measurement and calibration law, as well as MID. It comes with a display unit and a sensor unit which allows to serve applications in charging infrastructure and utility domains. The combination of the display unit (DU) and the sensor unit (SU) comprises the IEM-DCR models. The SU-1000 as a standalone is available as the IEM-DCS 1000.
| Product area: | Sensor |
|---|---|
| Current Range: | 0 - 1000 |
| Current Range Options: | 1000 |
| Voltage Range: | 0 - 1500 |
| Voltage Channels: | 4 |
| Interface: | OCMF over RF45 |
| Hardware setup: | 24 V |
| Configuration: | german calibration law, MID, LNE |
| Plating shunt: | nickel plated |
IEM-DCR-125
The IEM-DCR-125 complies with the German measurement and calibration law, as well as MID. It comes with a display unit and a sensor unit which allows to serve applications in charging infrastructure and utility domains. The combination of the display unit (DU) and the sensor unit (SU) comprises the IEM-DCR models. The SU-125 as a standalone is available as the IEM-DCS 125.
| Product area: | Sensor |
|---|---|
| Current Range: | 0 - 125 |
| Current Range Options: | 125 |
| Voltage Range: | 0 - 1000 |
| Voltage Channels: | 2 |
| Interface: | OCMF over RF45 |
| Hardware setup: | 24 V |
| Configuration: | german calibration law, MID, LNE |
IEM-DCR-1500
The IEM-DCR-1500 complies with the German measurement and calibration law, as well as MID. It comes with a display unit and a sensor unit which allows to serve applications in charging infrastructure and utility domains. The combination of the display unit (DU) and the sensor unit (SU) comprises the IEM-DCR models. The SU-1500 as a standalone is available as the IEM-DCS 1500.
| Product area: | Sensor |
|---|---|
| Current Range: | 0 - 1500 |
| Current Range Options: | 1500 |
| Voltage Range: | 0 - 1500 |
| Voltage Channels: | 4 |
| Interface: | OCMF over RF45 |
| Hardware setup: | 24 V |
| Configuration: | german calibration law, MID, LNE |
| Plating shunt: | nickel plated |
PBH
2-terminal resistor in space-saving design similar to TO-247. 10 W power – mounted on heat sink.
| Product area: | Resistor |
|---|---|
| Size: | TO-247 |
| Power (Watt): | 3 - 10 |
| Tol (%): | 0.500 - 5.00 |
| Res (Ohm): | 0.0036 - 100 |
PBV
4-terminal resistor wired. 10 W power – mounted on heat sink.
| Product area: | Resistor |
|---|---|
| Size: | 2317 |
| Power (Watt): | 3 - 10 |
| Tol (%): | 0.500 - 5.00 |
| Res (Ohm): | 0.0005 - 1 |
PMT
Pulse load resistor for snubber circuits or pre-charging and discharging applications.
| Product area: | Resistor |
|---|---|
| Size: | 2817 |
| Tol (%): | 10.0 |
| Res (Ohm): | 0.050 - 2.5 |
SMK
2-terminal resistor with large solder pads. Very powerful. Largest selection of resistor values up to 0.5 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 1 - 1.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.008 - 0.5 |
SMP
2-terminal resistor with large solder pads, very powerful. Largest selection of resistor values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 2 - 3 |
| Tol (%): | 0.500 - 1.00 |
| Res (Ohm): | 0.005 - 1 |
SMS
2-terminal resistor with large solder pads. Very powerful. Largest selection of resistance values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 3 - 5 |
| Tol (%): | 0.500 - 5.00 |
| Res (Ohm): | 0.005 - 1 |
SMT
2-terminal resistor with large solder pads. Very powerful. Largest selection of resistor values up to 4.7 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2817 |
| Power (Watt): | 5 - 7 |
| Tol (%): | 0.500 - 5.00 |
| Res (Ohm): | 0.004 - 4.7 |
VMK
2-terminal resistor. Standard solder pad geometry. Very low TC <20ppm/K for the entire value range. High continuous load, wide range of resistance values up to 470 mOhm.
| Product area: | Resistor |
|---|---|
| Size: | 1206 |
| Power (Watt): | 1 - 1.5 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.01 - 0.47 |
VMP
2-terminal resistor. Standard solder pad geometry. Very low TC <20ppm/K for the entire value range. High continuous load. Wide range of resistance values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2010 |
| Power (Watt): | 2 - 3 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.005 - 1 |
VMS
2-terminal resistor. Standard solder pad geometry. Very low TC <20ppm/K for the entire value range. High continuous load. Wide range of resistance values up to 1 Ohm.
| Product area: | Resistor |
|---|---|
| Size: | 2512 |
| Power (Watt): | 3 - 4 |
| Tol (%): | 1.00 - 5.00 |
| Res (Ohm): | 0.005 - 1 |
